Beginners, elites and families, step or jump for cardio health, then tone and strengthen upper body

The Plyometric Boxes are brilliant for new users right through to the super fit. They are a fantastic addition to your gym giving an excellent cardiovascular work out, improving heart and lung function. Users have the choice for people to step or jump at the right pace, height and range of movement for them. It allows progression for inactive people over time, as they build fitness and confidence.

The Plyometric Boxes also improve leg strength and overall tone. There are a number of exercise variations too. The bars around the edge enable users to perform incline and declined press ups, as well as tricep dips.

A really fun and low maintenance piece for kids and families too.

Features

  • Different height steps
  • Cardiovascular workout - jump or step up/ down
  • Upper body strength and tone exercises
  • Unlimited usage
  • Low maintenance, static piece

Benefits

  • Step up/ down or jump on different height levels, to suit your physical needs
  • Great for all ages including children
  • Inspires creative circuits and play
  • Great for personal training
  • Very affordable

Product details

Specification

  1. 100% Made in Britain
  2. Certified to EN16630, (legacy standards, BSI PAS888 - safety compliant for ALL ages, users and non-users & DIN79000 - safety compliant for users, aged 14+). All TGO outdoor gym equipment is free from exposed end stops, entrapments and sharp edges
    ALWAYS ASK FOR EN16630 FOR OUTDOOR GYMS
  3. Great instructional signage- workout QR code videos, start and finish diagrams.
  4. Weatherproof
  5. Resistance-based equipment - no electricity required
  6. Low maintenance
  7. Designs include key elements of Inclusive Fitness Initiative guidelines
  8. TGO plant a tree in the NHS Forest for every piece of equipment sold
  9. Anti vandal fixings
  10. Available in all major RAL colours
  11. Stop mechanisms concealed
  12. Paint UV stabilised
  13. Welds certified to EN15015614
  14. Powder coated finish
  15. Separate ground anchor for future upgrades

Production details

Manufacturer Standard: EN16630 (legacy standards - PAS888, Din79000)

Framework: Mild Steel Grade S275 (min 3mm thick)

Finish: High quality gloss finish polyester powder coat paint

Tread Plate: Aluminium

Signage Plate: High quality reverse printed PETG (found on the 400mm high box)

Enhanced corrosion protection

An enhanced corrosion protection is available on request for this product. Hot dip galvanising is the process TGO use to add a protective coating to the body of our products on our equipment in coastal areas, which have higher air salinity or in harsh urban and industrial atmospheres with higher sulphur dioxide pollution*.
The upgrade includes:

  • Upgrading to hot dip galvanising
  • Fixings are upgraded from A2 to A4 stainless steel

*An upgrade to galvanised steel will be necessary for the warranty in these environments.

Installation

These boxes are installed onto a series of concrete pads. For further information please refer to the ‘TGOGC Installation & Assembly Guidelines’. Please refer to the PDF below for safety spacing.

Safety

This product requires 1.5m of clear space around the equipment (green outline).

  • Falling height: 0.5m (based on the tallest box)
  • Clear Space: 22.3m² (when arranged as detailed top right)

There is no safer surface requirement and therefore TGO only recommend a minimal surface area (grey outline).

Parts list

No

Part

Dimensions

Weight

Qty

1

500 Plyometric Box

L525, W525, H501

19.5kg

1

2

400 Plyometric Box

L525, W525, H401

18.5kg

1

3

300 Plyometric Box

L525, W525, H301

17.5kg

1

4

HILTI Fixing

M12x145

0.1kg

12



This product can be mounted on medium anchors. Please request these if required:

No

Part

Dimensions

Weight

Qty

5

Medium Anchor

L429, W429, H344

14kg

3
